BT136 | Baldwin | Spin-On Filter Element | OFS # 97-25-0343
***Image may vary***

BT136 | Baldwin | OFS # 97-25-0343

  • $6.73

Spin-On Filter Element



Filter Availability - Usually Ships In 24 - 48 Hours


Performance Data
Micron Rating: 25.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 75 PSID

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Additional Notes: GMC CARS AND TRUCKS 350 V-8

Dimensional Specifications
Outer Diameter, Top: 3.69 IN (93.73 MM)

Outer Diameter, Bottom: 3.69 IN (93.73 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 5.41 IN (137.41 MM)

Thread: 13/16-16

Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL


Type of Media: PAPER

Filter Area: SQ.IN.


Outer Jacket: YES - METAL

Configuration: SINGLE OPEN END

Packaging Specifications
Number per Carton: 12

Carton Weight: 14.40 LB (6.53 KG)

Shipping Service: UPS Ground



All of Online Filter Supply replacement filters are "equivalent" to or "interchangeable" with the original filter manufacturer.

The names and part numbers found on this website are for reference only.

Please note that there is a minimum order amount of $25.00 on all orders.

Broken Cartons Are Available Upon Request.
