B43S | Baldwin | Spin-On Filter Element
***Image may vary***

B43S | Baldwin | Spin-On Filter Element

  • $7.20


OFS # 97-28-0477


Shipping & Packaging Specifications
Number Per Carton: 12 (Individual Filters Available)

Carton Weight: 8.00 LB (3.63 KG)

Stock Status: In Stock

Lead Time: Usually Ships In 24-48 Hours

Shipping Service: UPS Ground

Performance Data
Micron Rating: 20.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating:

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.00 IN (76.20 MM)

Outer Diameter, Bottom: 3.00 IN (76.20 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 3.50 IN (88.90 MM)

Thread: M18 X 1.5



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating:

Outer Jacket: YES - METAL

Configuration: SINGLE OPEN END



Cross References
Brand Part Number Visit Page
Baldwin B43 Visit Page
Baldwin B43S Visit Page
Baldwin B7446 Visit Page
Carquest 5040 Visit Page
Carquest 85040 Visit Page
Carquest 88614 Visit Page
Carquest 85040MP Visit Page
Carquest B111 Visit Page
Champion AR47 Visit Page
Champion G102 Visit Page
Champion G201 Visit Page
Champion OF02 Visit Page
Champion PH40 Visit Page
Champion PH47 Visit Page
Donaldson LFP550047 Visit Page
Donaldson P168011 Visit Page
Donaldson P172553 Visit Page
Donaldson P779180 Visit Page
Fleetguard LF711 Visit Page
Fleetguard LF780 Visit Page
FRAM DG3387A Visit Page
FRAM PH2862C Visit Page
FRAM PH3387 Visit Page
FRAM PH3387A Visit Page
FRAM PH3387AFP Visit Page
FRAM PH4722 Visit Page
FRAM PH4722A Visit Page
FRAM TG3387A Visit Page
Mahle OC68 Visit Page
Mahle OC7 Visit Page
Mahle OC90 Visit Page
MANN & HUMMEL W712/22 Visit Page
MANN & HUMMEL W918/2X Visit Page
NAPA 1040 Visit Page
NAPA 21040 Visit Page
NAPA 1040MP Visit Page
NAPA 21040MP Visit Page
Online Filter Supply 97-28-0477 Visit Page
WIX 12 Visit Page
WIX 22 Visit Page
WIX 51040 Visit Page
WIX 57032 Visit Page
WIX 85040 Visit Page
WIX 51040MP Visit Page
WIX 51040ST Visit Page
WIX WL7129 Visit Page
WIX WL7144 Visit Page

**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacturer parts, Names and part # used for cross reference only.**
