p550047 Donaldson Cross References Champion AR47
***Image may vary***

AR47 | Champion | Spin-On Filter Element

  • $7.20

OFS # 97-28-0477


Shipping & Packaging Specifications
Number Per Carton: 12 (Individual Filters Available)

Carton Weight: 8.00 LB (3.63 KG)

Stock Status: In Stock

Lead Time: Usually Ships In 24-48 Hours

Shipping Service: UPS Ground


Performance Data
Micron Rating:  20.00 NOMINAL

Beta Rating:  N/A

Collapse Pressure Rating:

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  3.00 IN   (76.20 MM)

Outer Diameter, Bottom:  3.00 IN   (76.20 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  3.50 IN   (88.90 MM)

Thread:  M18 X 1.5

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  PLASTISOL

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.


Outer Jacket:  YES - METAL

Configuration:  SINGLE OPEN END

Packaging Specifications
Number per Carton:  12

Carton Weight:  8.00 LB   (3.63 KG)


**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
