CW1509P | WIX | Pleated Paper Element | OFS # 97-01-0306
***Image may vary***

CW1509P | WIX | Pleated Paper Element | OFS # 97-01-0306

  • $15.52


PLEATED PAPER ELEMENT

Lead Time: Usually Ships In 24-28 Hours


Performance Data
Micron Rating: 10.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 75 PSID

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 4.52 IN (114.81 MM)

Outer Diameter, Bottom: 4.52 IN (114.81 MM)

Inner Diameter, Top: 1.80 IN (45.72 MM)

Inner Diameter, Bottom: 1.80 IN (45.72 MM)

Length: 7.00 IN (177.80 MM)

Thread: NONE



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES - METAL

Configuration: DOUBLE OPEN END



Packaging Specifications
Number per Carton: 1

Carton Weight: 1.10 LB (0.50 KG)
