R103| Technocar | OFS # 97-15-2582
Performance Data
Micron Rating: 20.00
Beta Rating: N/A BPV 36.26
Collapse Pressure Rating:
Maximum Temperature:
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 4.41 IN (112.01 MM)
Outer Diameter, Bottom: 4.41 IN (112.01 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 12.43 IN (315.72 MM)
Thread: M42 X 2-6H
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive:
Type of Endcap: PLATED STEEL
Center Tube: STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating:
Outer Jacket: YES
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 1
Carton Weight: 27.00 LB (12.25 KG) ***All Online Filter Supply replacement products are equivalent to or interchangeable with original manufacture parts***
