CS438 | Purflux | Fuel Filter Element
***Image may vary***

CS438 | Purflux | Fuel Filter Element | OFS # 97-15-1678

  • $35.40


FUEL FILTER ELEMENT Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 25.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.88 IN (98.55 MM)

Outer Diameter, Bottom:

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 5.45 IN (138.43 MM)

Thread: M20 X 1.5



Physical Specifications
Handle: NONE

Seal Material:

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating:

Outer Jacket: YES

Configuration: SINGLE OPEN SPIN ON



Packaging Specifications
Number per Carton: 12

Carton Weight: 18.20 LB (8.26 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
