L2020FN-30 | Luber-Finer | OFS # 97-01-0881

Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  30.00 NOMINAL

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:  250 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  4.31 IN   (109.47 MM)

Outer Diameter, Bottom:  4.31 IN   (109.47 MM)

Inner Diameter, Top:  0.63 IN   (16.00 MM)

Inner Diameter, Bottom:  0.81 IN   (20.57 MM)

Length:  8.90 IN   (226.06 MM)

Thread:  NONE

Physical Specifications
Handle:  NONE

Seal Material:

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:

Outer Jacket:  NONE

Configuration:

Packaging Specifications
Number per Carton:  12

Carton Weight:  15.50 LB   (7.03 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
