GL338 | Permatic | Spin-On Element | OFS # 97-25-0556

SPIN-ON ELEMENT Spin-On Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  0.00

Beta Rating:  N/A BPV 23.21

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  4.25 IN   (107.95 MM)

Outer Diameter, Bottom:  4.25 IN   (107.95 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  8.96 IN   (227.58 MM)

Thread:  1-12 UNF-2B

Physical Specifications
Handle:  NONE

Seal Material:

Type of Adhesive:  PLASTISOL

Type of Endcap:  PLATED STEEL

Center Tube:  STEEL

Type of Media:

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES

Configuration:  SINGLE OPEN SPIN-ON

Packaging Specifications
Number per Carton:  1

Carton Weight:  2.10 LB   (0.95 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
