FC505V | Permatic Replacement | OFS # 97-28-0885

Spin-On Filter Element In Stock

Performance Data
Micron Rating: 15.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating:

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Additional Notes: REPLACES BALDWIN # BF876

Dimensional Specifications
(A) Outer Diameter, Top: 4.26 IN (108.20 MM)

(B) Outer Diameter, Bottom: 4.26 IN (108.20 MM)

(C) Inner Diameter, Top:

(D) Inner Diameter, Bottom:

(E) Length: 8.11 IN (205.99 MM)

(F) Thread: 7/8-16 UN-2B

Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating:

Outer Jacket: YES - METAL

Configuration: SINGLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight: 22.10 LB (10.02 KG)
