AVAILABILITY - Usually ships in 24-48 hours

Larger order lead time 3 weeks

Performance Data
Micron Rating: 5.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 150 PSI

Maximum Temperature: N/A

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Dimensional Specifications
Outer Diameter, Top: 3.00 IN (76.20 MM)

Outer Diameter, Bottom: 3.00 IN (76.20 MM)

Inner Diameter, Top: 1.56 IN (39.62 MM)

Inner Diameter, Bottom: 1.56 IN (39.62 MM)

Length: 36.75 IN (933.45 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material: NONE

Type of Adhesive: N/A

Type of Endcap: N/A

Center Tube: CARBON STEEL

Type of Media: COTTON BLEND

Filter Area: N/A

Plating: N/A

Outer Jacket: YES

Configuration: DOUBLE OPEN W/SPRING

Packaging Specifications
Number per Carton: 12

Carton Weight: 32.00 LB (14.51 KG)

peco ft 336 c 5

**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
