PH2005 | Parts Plus | Spin-On Oil Filter
***Image may vary***

PH2005 | Parts Plus | Spin-On Oil Filter


Performance Data
Micron Rating:  25.00 NOMINAL

Beta Rating:  N/A

Collapse Pressure Rating:  75 PSID

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID



Dimensional Specifications
Outer Diameter, Top:  2.93 IN   (74.42 MM)

Outer Diameter, Bottom:  2.93 IN   (74.42 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  4.84 IN   (122.94 MM)

Thread:  3/4-16



Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  PLASTISOL

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES - METAL

Configuration:  SINGLE OPEN/SPIN-ON



Packaging Specifications
Number per Carton:  1

Carton Weight:  9.70 LB   (4.40 KG)



**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
