11525802 | Ford | Spin-On Element | OFS # 97-25-0533
***Image may vary***

11525802 | Ford | Spin-On Element | OFS # 97-25-0533

  • $12.64


In Stock

Performance Data
Micron Rating: 18.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 200 PSI

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
(A) Outer Diameter, Top: 3.00 IN (76.20 MM)

(B) Outer Diameter, Bottom: 3.00 IN (76.20 MM)

(C) Inner Diameter, Top:

(D) Inner Diameter, Bottom:

(E) Length: 3.53 IN (89.66 MM)

(F) Thread: 3/4"-16



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: 163.6 SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES - METAL

Configuration: SINGLE OPEN END



Packaging Specifications
Number per Carton: 12

Carton Weight: 4.20 LB (1.91 KG) ***All Online Filter Supply replacement parts are equivalent to or interchangable with original manufacture parts, Names and part # used for cross reference only.***
