CFG150A06A | MP FILTRI | OFS # 97-F7500-8K6B
***Image may vary***

CFG150A06A | MP FILTRI | OFS # 97-F7500-8K6B

  • $53.25


AVAILABILITY - Usually ships in 24-48 hours

Performance Data
Micron Rating: 6.00 ABSOLUTE

Beta Rating: B6 = 200

Collapse Pressure Rating: 100 PSID

Maximum Temperature: 250 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 50 PSID



Dimensional Specifications
Outer Diameter, Top: 5.06 IN (128.52 MM)

Outer Diameter, Bottom: 5.06 IN (128.52 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 11.00 IN (279.40 MM)

Thread: 1 1/2"-16



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: EPOXY

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: MICROGLASS

Filter Area: SQ.IN.

Plating: ZINC PLATED

Outer Jacket: YES - METAL

Configuration: SINGLE OPEN END



Packaging Specifications
Number per Carton: 1

Carton Weight: 3.00 LB

CROSS REFERENCE:
# 97-25-1141
OFS # 97-F7500-8K6B
Compatibility List For DONALDSON P165762
Replaces Description
0180MA003BN HYD FLTR
DONALDSON REPLACEMENT FOR HYDAC/HYCON 0180MA003BN
0180MA005BN HYD FLTR
DONALDSON REPLACEMENT FOR HYDAC/HYCON 0180MA005BN
020928 HYD FLTR
DONALDSON REPLACEMENT FOR LOESING 020928
12206090 HYD FLTR
DONALDSON REPLACEMENT FOR VOLVO 12206090
153408A HYD FLTR
DONALDSON REPLACEMENT FOR CHARLES MACHINE 153408A
153408B HYD FLTR
DONALDSON REPLACEMENT FOR DITCH WITCH 153408B
1810005 HYD FLTR
DONALDSON REPLACEMENT FOR ALLISON 1810005
1847 HYD FLTR
DONALDSON REPLACEMENT FOR NAPA 1847
210466 HYD FLTR
DONALDSON REPLACEMENT FOR BELL 210466
28403 HYD FLTR
DONALDSON REPLACEMENT FOR CMI 28403
284501 HYD FLTR
DONALDSON REPLACEMENT FOR CMI 284501
36784593 HYD FLTR
DONALDSON REPLACEMENT FOR INGERSOLL RAND 36784593
5002512 HYD FLTR
DONALDSON REPLACEMENT FOR EATON 5002512
51608503 HYD FLTR
DONALDSON REPLACEMENT FOR INGERSOLL RAND 51608503
51847 HYD FLTR
DONALDSON REPLACEMENT FOR WIX 51847
57804239 HYD FLTR
DONALDSON REPLACEMENT FOR INGERSOLL RAND 57804239
59124677 HYD FLTR
DONALDSON REPLACEMENT FOR INGERSOLL RAND 59124677
59124677 HYD FLTR
DONALDSON REPLACEMENT FOR SKYJACK 59124677
59879221 HYD FLTR
DONALDSON REPLACEMENT FOR INGERSOLL RAND 59879221
603M HYD FLTR
DONALDSON REPLACEMENT FOR NORMAN ULTRAPOROUS 603M
605599 HYD FLTR
DONALDSON REPLACEMENT FOR MARINE TRAVELIFT, INC. 605599
605599 HYD FLTR
DONALDSON REPLACEMENT FOR SHUTTLELIFT INC 605599
606M HYD FLTR
DONALDSON REPLACEMENT FOR NORMAN ULTRAPOROUS 606M
687260 HYD FLTR
DONALDSON REPLACEMENT FOR UNITED CENTRAL INDUSTRIAL SUPP 687260
710202 HYD FLTR
DONALDSON REPLACEMENT FOR AG CHEM EQUIPMENT 710202
750083UMSF HYD FLTR
DONALDSON REPLACEMENT FOR TRIBOGUARD 750083UMSF
80933120 HYD FLTR
DONALDSON REPLACEMENT FOR JLG 80933120
85847 HYD FLTR
DONALDSON REPLACEMENT FOR CARQUEST 85847
8T5549 HYD FLTR
DONALDSON REPLACEMENT FOR CATERPILLAR 8T5549
932037 HYD FLTR
DONALDSON REPLACEMENT FOR PARKER 932037
932073 HYD FLTR
DONALDSON REPLACEMENT FOR PARKER 932073
932079 HYD FLTR
DONALDSON REPLACEMENT FOR PARKER 932079
9576P165762 HYD FLTR
DONALDSON REPLACEMENT FOR FORD 9576P165762
9U6983 HYD FLTR
DONALDSON REPLACEMENT FOR CATERPILLAR 9U6983
A152G03 HYD FLTR
DONALDSON REPLACEMENT FOR FILTREC A152G03
A152G06 HYD FLTR
DONALDSON REPLACEMENT FOR FILTREC A152G06
A152G06 HYD FLTR
DONALDSON REPLACEMENT FOR MAIN FILTER A152G06
AFS51103 HYD FLTR
DONALDSON REPLACEMENT FOR AIR HYDRAULIC SYSTEMS AFS51103
AFS51106 HYD FLTR
DONALDSON REPLACEMENT FOR AIR HYDRAULIC SYSTEMS AFS51106
AG710202 HYD FLTR
DONALDSON REPLACEMENT FOR AG CHEM EQUIPMENT AG710202
BT8422MPG HYD FLTR
DONALDSON REPLACEMENT FOR BALDWIN BT8422MPG
CFG150A06A HYD FLTR
DONALDSON REPLACEMENT FOR MP FILTRI CFG150A06A
CSG150A03A HYD FLTR
DONALDSON REPLACEMENT FOR MP FILTRI CSG150A03A
CSG150A06A HYD FLTR
DONALDSON REPLACEMENT FOR MP FILTRI CSG150A06A
DNEHF7832 HYD FLTR
DONALDSON REPLACEMENT FOR FREIGHTLINER DNEHF7832
DNP167832 HYD FLTR
DONALDSON REPLACEMENT FOR FREIGHTLINER DNP167832
E0211B2R03 HYD FLTR
DONALDSON REPLACEMENT FOR WESTERN FILTER E0211B2R03
E0211B2R05 HYD FLTR
DONALDSON REPLACEMENT FOR WESTERN FILTER E0211B2R05
ESF22NFB HYD FLTR
DONALDSON REPLACEMENT FOR UFI ESF22NFB
F439069 HYD FLTR
DONALDSON REPLACEMENT FOR CASE/CASE IH F439069
F4E070GCB HYD FLTR
DONALDSON REPLACEMENT FOR PTI F4E070GCB
F4E070HCB HYD FLTR
DONALDSON REPLACEMENT FOR PTI F4E070HCB
F4E071GCB HYD FLTR
DONALDSON REPLACEMENT FOR PTI F4E071GCB
F4E071HCB HYD FLTR
DONALDSON REPLACEMENT FOR PTI F4E071HCB
F4F070GDB HYD FLTR
DONALDSON REPLACEMENT FOR PTI F4F070GDB
F4F070HCB HYD FLTR
DONALDSON REPLACEMENT FOR PTI F4F070HCB
FC1068 HYD FLTR
DONALDSON REPLACEMENT FOR FLUID CONTROL SERVICES FC1068
FCAF HYD FLTR
DONALDSON REPLACEMENT FOR DES CASE FCAF
FCBF HYD FLTR
DONALDSON REPLACEMENT FOR DES CASE FCBF
FPD0201047 HYD FLTR
DONALDSON REPLACEMENT FOR FPS FPD0201047
FPE7003G HYD FLTR
DONALDSON REPLACEMENT FOR FPC FPE7003G
FPE7005G HYD FLTR
DONALDSON REPLACEMENT FOR FPC FPE7005G
H439069 HYD FLTR
DONALDSON REPLACEMENT FOR CASE/CASE IH H439069
H511105D261 HYD FLTR
DONALDSON REPLACEMENT FOR FLUITEK H511105D261
H511105M261 HYD FLTR
DONALDSON REPLACEMENT FOR FLUITEK H511105M261
H51112D26 HYD FLTR
DONALDSON REPLACEMENT FOR FLUITEK H51112D26
H51112M26 HYD FLTR
DONALDSON REPLACEMENT FOR FLUITEK H51112M26
HC7500FKP8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL HC7500FKP8H
HC7500SDN8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL HC7500SDN8H
HC7500SDP8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL HC7500SDP8H
HC7500SKN8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL HC7500SKN8H
HC7500SKP8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL HC7500SKP8H
HC7500SUN8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL HC7500SUN8H
HC7500SUP8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL HC7500SUP8H
HC9500SUP8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL HC9500SUP8H
HF0670700 HYD FLTR
DONALDSON REPLACEMENT FOR AG CHEM EQUIPMENT HF0670700
HF165762 HYD FLTR
DONALDSON REPLACEMENT FOR VMC HF165762
HF167832 HYD FLTR
DONALDSON REPLACEMENT FOR VMC HF167832
HF6704 HYD FLTR
DONALDSON REPLACEMENT FOR FLEETGUARD HF6704
HF6707 HYD FLTR
DONALDSON REPLACEMENT FOR FLEETGUARD HF6707
HF6776 HYD FLTR
DONALDSON REPLACEMENT FOR FLEETGUARD HF6776
HF6778 HYD FLTR
DONALDSON REPLACEMENT FOR FLEETGUARD HF6778
HF740 HYD FLTR
DONALDSON REPLACEMENT FOR HASTINGS HF740
HP75L83MB HYD FLTR
DONALDSON REPLACEMENT FOR HY PRO HP75L83MB
HP75L86MB HYD FLTR
DONALDSON REPLACEMENT FOR HY PRO HP75L86MB
KL580011 HYD FLTR
DONALDSON REPLACEMENT FOR KELTEC KL580011
LFH4989 HYD FLTR
DONALDSON REPLACEMENT FOR LUBER-FINER LFH4989
LFH4997 HYD FLTR
DONALDSON REPLACEMENT FOR LUBER-FINER LFH4997
LFH50113 HYD FLTR
DONALDSON REPLACEMENT FOR LUBER-FINER LFH50113
LSP14 HYD FLTR
DONALDSON REPLACEMENT FOR HEIL LSP14
MC7500SKN8H HYD FLTR
DONALDSON REPLACEMENT FOR PALL MC7500SKN8H
MEE160105BN2 HYD FLTR
DONALDSON REPLACEMENT FOR HYDAC/HYCON MEE160105BN2
MFE160103BN2 HYD FLTR
DONALDSON REPLACEMENT FOR HYDAC/HYCON MFE160103BN2
MFE160105BN2 HYD FLTR
DONALDSON REPLACEMENT FOR HYDAC/HYCON MFE160105BN2
MFE18003BN2 HYD FLTR
DONALDSON REPLACEMENT FOR HYDAC/HYCON MFE18003BN2
MFE18005BN2 HYD FLTR
DONALDSON REPLACEMENT FOR HYDAC/HYCON MFE18005BN2
P564055 HYD FLTR
DONALDSON REPLACEMENT FOR REPLACED BY P564055
P6020 HYD FLTR
DONALDSON REPLACEMENT FOR DES CASE P6020
P6021 HYD FLTR
DONALDSON REPLACEMENT FOR DES CASE P6021
P7254 HYD FLTR
DONALDSON REPLACEMENT FOR FRAM P7254
PR3962 HYD FLTR
DONALDSON REPLACEMENT FOR PARKER PR3962
R750H0803A HYD FLTR
DONALDSON REPLACEMENT FOR FAIREY ARLON R750H0803A
R750H0806A HYD FLTR
DONALDSON REPLACEMENT FOR FAIREY ARLON R750H0806A
SBF75008S3B HYD FLTR
DONALDSON REPLACEMENT FOR SCHROEDER SBF75008S3B
SBF75008Z3B HYD FLTR
DONALDSON REPLACEMENT FOR SCHROEDER SBF75008Z3B
SBF75008Z5B HYD FLTR
DONALDSON REPLACEMENT FOR SCHROEDER SBF75008Z5B
SF6703MG2 HYD FLTR
DONALDSON REPLACEMENT FOR STAUFF SF6703MG2
SF6704MG2 HYD FLTR
DONALDSON REPLACEMENT FOR STAUFF SF6704MG2
SF6707 HYD FLTR
DONALDSON REPLACEMENT FOR STAUFF SF6707
SH56754 HYD FLTR
DONALDSON REPLACEMENT FOR JURA FILTRATION SH56754
SH56757 HYD FLTR
DONALDSON REPLACEMENT FOR JURA FILTRATION SH56757
SPE60BTA3 HYD FLTR
DONALDSON REPLACEMENT FOR LHA SPE60BTA3
SPH20101 HYD FLTR
DONALDSON REPLACEMENT FOR SF-Filter SPH20101
SPH20103 HYD FLTR
DONALDSON REPLACEMENT FOR SF-Filter SPH20103
ST6704 HYD FLTR
DONALDSON REPLACEMENT FOR SEPARATION TECHNOLOGIES ST6704
ST6707 HYD FLTR
DONALDSON REPLACEMENT FOR SEPARATION TECHNOLOGIES ST6707
V0211B2R03 HYD FLTR
DONALDSON REPLACEMENT FOR EATON V0211B2R03
V0211B2R03 HYD FLTR
DONALDSON REPLACEMENT FOR VICKERS V0211B2R03
V0211B2R03S HYD FLTR
DONALDSON REPLACEMENT FOR EATON V0211B2R03S
V0211B2R05 HYD FLTR
DONALDSON REPLACEMENT FOR VICKERS V0211B2R05
V0211B2V03 HYD FLTR
DONALDSON REPLACEMENT FOR VICKERS V0211B2V03
V0211B2V05 HYD FLTR
DONALDSON REPLACEMENT FOR VICKERS V0211B2V05
ZLE03 HYD FLTR
DONALDSON REPLACEMENT FOR ZINGA ZLE03
ZLE03P HYD FLTR
DONALDSON REPLACEMENT FOR ZINGA ZLE03P

**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
