AC56 | Luber-Finer | Spin-On Element
***Image may vary***

AC56 | Luber-Finer | Spin-On Element | OFS # 97-25-0509

  • $13.40


SPIN-ON ELEMENT Spin-On Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 15.00 NOMINAL

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.03 IN (76.96 MM)

Outer Diameter, Bottom: 3.03 IN (76.96 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 6.14 IN (155.96 MM)

Thread: M16 X 1.5-6H



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES

Configuration: SINGLE OPEN SPIN ON



Packaging Specifications
Number per Carton: 12

Carton Weight: 12.80 LB (5.81 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
