A110C25 | Filtrec | OFS # 97-25-0617
Performance Data
Micron Rating: 25.00
Beta Rating: N.A.
Collapse Pressure Rating: 80 PSID
Maximum Temperature: 300 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 3.70 IN (93.98 MM)
Outer Diameter, Bottom: 3.70 IN (93.98 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 5.30 IN (134.62 MM)
Thread: 3/4-14BSP
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: PAPER
Filter Area: 3.3 SQ.FT.
Plating: ELECTROTIN PLATED
Outer Jacket: NONE
Configuration:
Packaging Specifications
Number per Carton: 12
Carton Weight: **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
