626 | Crosland | Full Flow Lube Filter Element | OFS # 97-28-1298
Usually Ships In 24-48 Hours
Performance Data
Micron Rating: 25.00 NOMINAL
Beta Rating: N/A
Collapse Pressure Rating: 75 PSID
Maximum Temperature: 225 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 5.00 IN (127.00 MM)
Outer Diameter, Bottom: 5.00 IN (127.00 MM)
Inner Diameter, Top: 1.48 IN (37.59 MM)
Inner Diameter, Bottom: 1.48 IN (37.59 MM)
Length: 9.66 IN (245.36 MM)
Thread: NONE
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating: ELECTROTIN PLATED
Outer Jacket: YES - METAL
Configuration: DOUBLE OPEN END
Packaging Specifications
Number per Carton: 12
Carton Weight: 20.40 LB (9.25 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
