42361 | WIX | OFS # 97-28-4077

Lead Time: Please Call

Performance Data
Micron Rating: 15.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Dimensional Specifications
Outer Diameter, Top: 4.40 IN (111.76 MM)

Outer Diameter, Bottom: 2.74 IN (69.60 MM)

Inner Diameter, Top: 3.15 IN (80.01 MM)

Inner Diameter, Bottom: 1.50 IN (38.10 MM)

Length: 2.25 IN (57.15 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material: MOLDED

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating:

Outer Jacket: YES

Configuration: DOUBLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight:
