42244 | WIX | OFS # 97-28-1877

Lead Time: Please Call

Performance Data
Micron Rating: 15.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Dimensional Specifications
Outer Diameter, Top: 10.25 IN (260.35 MM)

Outer Diameter, Bottom:

Inner Diameter, Top: 5.50 IN (139.70 MM)

Inner Diameter, Bottom:

Length: 6.03 IN (153.16 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material:

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating:

Outer Jacket: YES

Configuration: DOUBLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight: 3.90 LB (1.77 KG)
