90E10CSN | 3B Filters | OFS # 97-25-0039

Packaging Specifications

Lead Time: Usually Ships In 24-48 Hours

Shipping Service: UPS GROUND

Number Per Carton:  6

Carton Weight: 18.00 LB   (8.16 KG)

Performance Data
Micron Rating:  3.00 NOMINAL

Beta Rating:  N/A

Collapse Pressure Rating:  100 PSID

Maximum Temperature:  250 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Dimensional Specifications
Outer Diameter, Top: 5.06 IN (128.52 MM)

Outer Diameter, Bottom: 5.06 IN (128.52 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 11.00 IN (279.40 MM)

Thread: 1 1/2"-16

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Filter:  SPIN-ON FILTER ELEMENT

Type of Adhesive:  EPOXY

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES - METAL

Configuration:  SINGLE OPEN END

**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacturer parts, Names and part # used for cross reference only.**
