P551268 | Donaldson | Spin-on Filter Element | OFS # 97-01-0713
Performance Data
Micron Rating: 18.00 NOMINAL
Beta Rating: N/A
Collapse Pressure Rating: 75 PSID
Maximum Temperature: 225 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 3.69 IN (93.73 MM)
Outer Diameter, Bottom: 3.69 IN (93.73 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 4.13 IN (104.90 MM)
Thread: 3/4-16
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: PLASTISOL
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating: N/A
Outer Jacket: YES - METAL
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 12
Carton Weight: 13.40 LB (6.08 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
