P551183 | DONALDSON | Pleated Paper Filter Element
***Image may vary***

P551183 | Donaldson | OFS # 97-01-0420

  • $22.16


Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 10.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 75 PSID

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Additional Notes: ONE END HAS BOLT HOLE



Dimensional Specifications
Outer Diameter, Top: 4.53 IN (115.06 MM)

Outer Diameter, Bottom: 4.53 IN (115.06 MM)

Inner Diameter, Top: 0.50 IN (12.70 MM)

Inner Diameter, Bottom: 2.28 IN (57.91 MM)

Length: 7.06 IN (179.32 MM)

Thread: NONE



Physical Specifications
Handle: NONE

Seal Material: BUNA/FI

Type of Adhesive: POLYVINYLCHLORIDE

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES

Configuration:



Packaging Specifications
Number per Carton: 1

Carton Weight: 1.20 LB (0.54 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
