MP16123 | Mp Filtri | Return-Line Element | OFS # 97-05-0303

Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  3.00 ABSOLUTE

Beta Rating:  B3 = 200

Collapse Pressure Rating:  300 PSID

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  50 PSID

Dimensional Specifications
Outer Diameter, Top:  2.06 IN   (52.32 MM)

Outer Diameter, Bottom:  2.06 IN   (52.32 MM)

Inner Diameter, Top:  0.88 IN   (22.35 MM)

Inner Diameter, Bottom:

Length:  4.00 IN   (101.60 MM)

Thread:  NONE

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  EPOXY

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  MICROGLASS

Filter Area:  SQ.IN.

Plating:  ZINC PLATED

Outer Jacket:  NONE - NONE

Configuration:  ZINC PLATED

Packaging Specifications
Number per Carton:  1

Carton Weight:  5.00 LB   (2.27 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
