MF0063272 | Main Filter Grou | Pleated Wire Element | OFS # 97-06-0627

PLEATED WIRE ELEMENT Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 149.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 25 PSID

Dimensional Specifications
Outer Diameter, Top: 2.50 IN (63.50 MM)

Outer Diameter, Bottom:

Inner Diameter, Top: 1.50 IN (38.10 MM)

Inner Diameter, Bottom:

Length: 9.75 IN (247.65 MM)

Thread:

Physical Specifications
Handle: NONE

Seal Material:

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: 304 SS WIRE

Filter Area: SQ.IN.

Plating:

Outer Jacket: NONE

Configuration:

Packaging Specifications
Number per Carton: 1

Carton Weight: **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
