HD223L | Ac Delco | Spin-On Element
***Image may vary***

HD223L | Ac Delco | Spin-On Element | OFS # 97-25-0366

  • $20.10

SPIN-ON ELEMENT Spin-On Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  20.00

Beta Rating:  N/A

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  4.67 IN   (118.62 MM)

Outer Diameter, Bottom:  4.67 IN   (118.62 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  10.30 IN   (261.62 MM)

Thread:  1 5/16-12

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.


Outer Jacket:  YES

Configuration:  SINGLE OPEN END

Packaging Specifications
Number per Carton:  1

Carton Weight:  3.20 LB   (1.45 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
