OFS# 97-25-0349



Performance Data
Micron Rating:  25.00 NOMINAL

Beta Rating:  N/A

Collapse Pressure Rating:  75 PSID

Maximum Tempeature:  225 F

Max Heat - 225 Ferihent

Direction of Flow:  OUTSIDE->IN

Recommended Change-out Differential Pressure:  20 PSID

Dimensional Specifications

Outer Diameter, Top:  3.70 Inches  (93.98 MM)

Outer Diameter, Bottom:  3.70 Inches   (93.98 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  3.88 Inches  (98.55 MM)

Thread:  3/4-16 UNF-2B



Physical Specifications

Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  PLASTISOL

Adhesive Type - Plastisol

Type of End-cap:  PLATED STEEL

End cap Type - Plated Steal

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Media Type - Paper

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES - METAL

Jacket Outer -

Configuration:  SINGLE OPEN END



Packaging Specifications

Number per Carton:  12

Carton Weight:  13.30 LB ( Please contact for availability of broken cases)
