R2198P| Ryco | Fuel Spin-On Filter OFS # 97-28-0808

Usually ships in 24-48 hours Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  15.00 NOMINAL

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:  225 F

Direction of Flow:  INSIDE->OUT

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  3.31 IN   (84.07 MM)

Outer Diameter, Bottom:  3.31 IN   (84.07 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  3.22 IN   (81.79 MM)

Thread:  3/4-16 UNF-2B

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:

Type of Endcap:  STEEL

Center Tube:  STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:  N/A

Outer Jacket:  YES - METAL

Configuration:  SINGLE OPEN SPIN ON

Packaging Specifications
Number per Carton:  12

Carton Weight:  9.80 LB   (4.45 KG) ***All Online Filter Supply replacement products are equivalent to or interchangeable with original manufacture parts***
