Q10060200001| Halla | Fuel Filter Element | OFS # 97-28-9638

FUEL FILTER ELEMENT

Performance Data
Micron Rating:  25.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  3.15 IN   (80.01 MM)

Outer Diameter, Bottom:  3.15 IN   (80.01 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  4.88 IN   (123.95 MM)

Thread:  M20 X 1.56H

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:  STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:

Outer Jacket:  YES

Configuration:  SINGLE OPEN / HOLE

Packaging Specifications
Number per Carton:  1

Carton Weight: ***All Online Filter Supply replacement products are equivalent to or interchangeable with original manufacture parts***
