Parker (Singapore)
Regular price
$1,899.99 USD
Regular price
Sale price
$1,899.99 USD
Quantity
Couldn't load pickup availability
60 DAY LEAD TIME
| PERFORMANCE CHARACTERISTICS | Parker/Singapore Product Is Only Available Upon Request |
| Available Accessories | Horizontal Drain Kit 5000 PSIG (JDK5000H), Vertical Drain Kit 5000 PSIG (JDK5000V), Differential Pressure Gauge and Bracket (BDPI-25) |
| Bowl Material | Steel |
| Brand | Finite |
| Coating Option | Epoxy Powder Paint |
| Drain Port Size | SAE-6 |
| Materials Head | Spheroidal Graphic Cast Iron |
| Maximum Operating Pressure (Bar) | 345 |
| Maximum Operating Pressure (PSIG) | 5000 |
| Maximum Operating Temperature (C) | 175 |
| Maximum Operating Temperature (F) | 350 |
| Plating | Nickel Plated |
| Replacement Element | J Series Filter Replacement Elements |
| Seal Material | Fluorocarbon |
| Weight (Kg) | 4.1-30.4 depending on configuration |
| Weight (Lbs) | 9.0-67.0 depending on configuration |
|
FILTER RATING (%): |
99.995 |
|
FILTER TYPE: |
Coalescer |
|
MAXIMUM FLOW RATE (CFM): |
3935 at 5000 PSI |
|
MICRON RATING (ΜM): |
0.01 |
|
PART NUMBER: |
JN4C-4CN |
|
THREAD TYPE: |
NPT |
|
PORT CONNECTION (INCH): |
1 |
