P779667 | DONALDSON | Spin-on Filter Element
***Image may vary***

P779667 | Donaldson | Spin-on Filter Element | OFS # 97-25-0562

  • $8.78


Spin-On Filter Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 15.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 75 PSID

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.73 IN (94.74 MM)

Outer Diameter, Bottom: 3.73 IN (94.74 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 3.84 IN (97.54 MM)

Thread: 1-12 UNF-2B



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES

Configuration: SINGLE OPEN SPIN-ON



Packaging Specifications
Number per Carton: 1

Carton Weight: 11.80 LB (5.35 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
