P558250 | DONALDSON | Spin-on Filter Element
***Image may vary***

P558250 | Donaldson | Spin-on Filter Element | OFS # 97-25-0380

  • $13.51


Spin-On Filter Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 23.00

Beta Rating: N/A BPV 13.49

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.78 IN (96.01 MM)

Outer Diameter, Bottom: 3.78 IN (96.01 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 6.88 IN (174.75 MM)

Thread: 1-12 UNF2B



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: STEEL

Center Tube: STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES

Configuration: SINGLE OPEN END



Packaging Specifications
Number per Carton: 1

Carton Weight: 16.70 LB (7.57 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
