P550704 | DONALDSON | Spin-on Filter Element
***Image may vary***

P550704 | Donaldson | Spin-on Filter Element | OFS # 97-25-0665

  • $28.12


Spin-On Filter Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 10.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.74 IN (95.00 MM)

Outer Diameter, Bottom: 3.74 IN (95.00 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 5.83 IN (148.08 MM)

Thread: 1 1/2-16 UN2B



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media: MICROGLASS

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES

Configuration: SINGLE OPEN SPIN ON



Packaging Specifications
Number per Carton: 1

Carton Weight: 1.40 LB (0.64 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
