P502062 | DONALDSON | Spin-on Filter Element
***Image may vary***

P502062 | Donaldson | Spin-on Filter Element | OFS # 97-25-0465

  • $11.27


Spin-On Filter Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 0.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 2.56 IN (65.02 MM)

Outer Diameter, Bottom: 2.56 IN (65.02 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 3.50 IN (88.90 MM)

Thread: M20X1.5



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media:

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES - METAL

Configuration: SINGLE OPEN END



Packaging Specifications
Number per Carton: 12

Carton Weight: 6.00 LB (2.72 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
