P172651 | DONALDSON | Fuel Filter Element
***Image may vary***

P172651 | Donaldson | Fuel Filter Element | OFS # 97-28-0187

  • $7.72


FUEL FILTER ELEMENT Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 4.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 75 PSID

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.44 IN (87.38 MM)

Outer Diameter, Bottom: 3.44 IN (87.38 MM)

Inner Diameter, Top: 0.75 IN (19.05 MM)

Inner Diameter, Bottom: 1.50 IN (38.10 MM)

Length: 2.81 IN (71.37 MM)

Thread: NONE



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating: NONE

Outer Jacket: YES

Configuration: DOUBLE OPEN END



Packaging Specifications
Number per Carton: 12

Carton Weight: 6.00 LB (2.72 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
