HFP171603 | DONALDSON | Pleated Paper Filter Element
***Image may vary***

HFP171603 | Donaldson | OFS # 97-01-1007

  • $10.04

Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 10.00 NOMINAL

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Dimensional Specifications
Outer Diameter, Top: 4.62 IN (117.35 MM)

Outer Diameter, Bottom: 4.62 IN (117.35 MM)

Inner Diameter, Top: 2.20 IN (55.88 MM)

Inner Diameter, Bottom: 2.20 IN (55.88 MM)

Length: 5.47 IN (138.94 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive:

Type of Endcap: PLATED STEEL


Type of Media: PAPER

Filter Area: SQ.IN.


Outer Jacket: YES

Configuration: DOUBLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight: 11.80 LB (5.35 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
