Dimensional Specifications Outer Diameter, Top: 3.32 IN (84.33 MM)
Outer Diameter, Bottom: 3.32 IN (84.33 MM)
Inner Diameter, Top: 1.87 IN (47.50 MM)
Inner Diameter, Bottom:
Length: 5.56 IN (141.22 MM)
Thread: NONE
Physical Specifications Handle: NONE
Seal Material: NONE
Type of Adhesive: EPOXY
Type of Endcap: PLATED STEEL
Center Tube: PLATED STEEL
Type of Media: MICROGLASS
Filter Area: 303 SQ.IN.
Plating: ZINC PLATE
Outer Jacket: NONE
Configuration: SINGLE OPEN END
Packaging Specifications Number per Carton: 1
Carton Weight: 2.00 LB (0.91 KG)
**All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
