CW11DG | WIX | Sock Type, By-Pass, Lube | OFS # 97-10-0116
***Image may vary***

CW11DG | WIX | Sock Type, By-Pass, Lube | OFS # 97-10-0116

  • $14.63


Performance Data
Micron Rating: 0.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 25 PSID



Dimensional Specifications
Outer Diameter, Top: 4.00 IN (101.60 MM)

Outer Diameter, Bottom:

Inner Diameter, Top: 0.56 IN (14.22 MM)

Inner Diameter, Bottom: 1.38 IN (35.05 MM)

Length: 5.25 IN (133.35 MM)

Thread: NONE



Physical Specifications
Handle: NONE

Seal Material:

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube:

Type of Media: COTTON

Filter Area: SQ.IN.

Plating:

Outer Jacket: NONE

Configuration:



Packaging Specifications
Number per Carton: 1

Carton Weight: 13.00 LB (5.90 KG)
