CA60.3 | Donaldson | Spin-On Filter Element
***Image may vary***

CA60.3 | Donaldson | OFS # 97-25-0617

  • $20.70


Spin-On Filter Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating: 25.00

Beta Rating: N.A.

Collapse Pressure Rating: 80 PSID

Maximum Temperature: 300 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.70 IN (93.98 MM)

Outer Diameter, Bottom: 3.70 IN (93.98 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 5.30 IN (134.62 MM)

Thread: 3/4-14BSP



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: 3.3 SQ.FT.

Plating: ELECTROTIN PLATED

Outer Jacket: NONE

Configuration:



Packaging Specifications
Number per Carton: 12

Carton Weight: **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
