B6 | Baldwin | Spin-On Filter Element | OFS # 97-25-0343
***Image may vary***

B6 | Baldwin | OFS # 97-25-0343

  • $6.73


Spin-On Filter Element





Filter Availability - Usually Ships In 24 - 48 Hours



Performance Data
Micron Rating: 25.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 75 PSID

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Additional Notes: GMC CARS AND TRUCKS 350 V-8



Dimensional Specifications
Outer Diameter, Top: 3.69 IN (93.73 MM)

Outer Diameter, Bottom: 3.69 IN (93.73 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 5.41 IN (137.41 MM)

Thread: 13/16-16



Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PLASTISOL

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES - METAL

Configuration: SINGLE OPEN END



Packaging Specifications
Number per Carton: 12

Carton Weight: 14.40 LB (6.53 KG)

Shipping Service: UPS Ground





All of Online Filter Supply replacement filters are "equivalent" to or "interchangeable" with the original filter manufacturer.

The names and part numbers found on this website are for reference only.

Please note that there is a minimum order amount of $25.00 on all orders.

Broken Cartons Are Available Upon Request.
