Performance Data
Micron Rating: 6.00 ABSOLUTE

Beta Rating: B6 = 200

Collapse Pressure Rating: 100 PSID

Maximum Temperature: 250 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 50 PSID

Dimensional Specifications
Outer Diameter, Top: 3.75 IN  (95.25 MM)

Outer Diameter, Bottom: 3.75 IN  (95.25 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length: 5.50 IN  (139.70 MM)

Thread: 1 1/2"-16

Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: EPOXY

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media:  MICROGLASS

Filter Area: SQ.IN.

Plating: ZINC PLATED

Outer Jacket: YES - METAL

Configuration: SINGLE OPEN END

Packaging Specifications
Number per Carton: 6

Carton Weight:  9.00 LB  (4.08 KG)
