524317 | WIX | Pleated Paper Element | OFS # 97-01-0865
***Image may vary***

524317 | WIX | Pleated Paper Element | OFS # 97-01-0865

  • $8.67


PLEATED PAPER ELEMENT

Lead Time: Usually Ships In 24-28 Hours


Performance Data
Micron Rating: 0.00 NOMINAL

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature: 250 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID



Dimensional Specifications
Outer Diameter, Top: 3.28 IN (83.31 MM)

Outer Diameter, Bottom:

Inner Diameter, Top: 1.25 IN (31.75 MM)

Inner Diameter, Bottom:

Length: 5.13 IN (130.30 MM)

Thread: NONE



Physical Specifications
Handle: NONE

Seal Material:

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating:

Outer Jacket: YES

Configuration:



Packaging Specifications
Number per Carton: 1

Carton Weight: 6.40 LB (2.90 KG)
