Usually ships in 24-48 hours Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  20.00 NOMINAL

Beta Rating:  N.A.

Collapse Pressure Rating:  75 PSID

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Additional Notes:  COMES COMPLETE WITH COVER GASKETS.

Dimensional Specifications
Outer Diameter, Top:  3.95 IN   (100.33 MM)

Outer Diameter, Bottom:  3.95 IN   (100.33 MM)

Inner Diameter, Top:  1.08 IN   (27.43 MM)

Inner Diameter, Bottom:  1.08 IN   (27.43 MM)

Length:  5.95 IN   (151.13 MM)

Thread:  NONE

Physical Specifications
Handle:  NONE

Seal Material:  BUNA-N

Type of Adhesive:  PVC

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:  ZINC PLATED

Outer Jacket:  YES - PAPER

Configuration:  DOUBLE OPEN END

Packaging Specifications
Number per Carton:  1

Carton Weight:  0.95 LB   (0.43 KG) ***All Online Filter Supply replacement products are equivalent to or interchangeable with original manufacture parts***
