Performance Data
Micron Rating:  25.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  4.39 IN   (111.51 MM)

Outer Diameter, Bottom:  4.39 IN   (111.51 MM)

Inner Diameter, Top:  2.44 IN   (61.98 MM)

Inner Diameter, Bottom:

Length:  16.00 IN   (406.40 MM)

Thread:  NONE

Physical Specifications
Handle:  NONE

Seal Material:

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:  STEEL

Type of Media:  PAPER

Filter Area:  SQ.IN.

Plating:

Outer Jacket:  YES

Configuration:  SINGLE OPEN END

Packaging Specifications
Number per Carton:  1

Carton Weight:  18.70 LB   (8.48 KG) ***All Online Filter Supply replacement products are equivalent to or interchangeable with original manufacture parts***
