P550398 | Donaldson Fuel Filter | OFS # 97-30-3593

Cross Reference For Donaldson P550398 | Fuel Filter | OFS # 97-30-3593
Caterpillar 131-1812 John Deere RE53729 RE62421 ASAS-SP4044 BALDWIN-BF1238 BF7672D BF9833D BIG A-95638 CARQUEST-86638 86649 CATERPILLAR-1311812 CHAMPION ROAD-26826 FLEETGUARD-FS19554 FS19589 FS19839 FS19979 FLEETRITE-FSR819554 FSR819589 FRAM-PS7409 PS7409A PS8533 GREYFRIARS-4000F HASTINGS-FF1046 FF1100 FF1100D HIFI FILTER - JURA FILTRATION-SN70137 SN70261 JCB-32925760 JOHN DEERE-RE53729 RE62421 KRALINATOR-FS249 LIEBHERR-7381877 LOESING-25166 25166 LUBER FINER-L8681F MANN & HUMMEL-WK8108 WK8110 WK8138 NAPA-3638 3649 PUROLATOR-6939842 F65171 REPLACED BY-P550398 P550503 ROOSAMASTER-30422 31387 31734 31865 32650 SF-FILTER-SK3429 STANADYNE-30422 31387 31734 31865 32650 36810 37932 31734DN VMC-FS550503 FS550772 WISCONSIN-31387 WIX-33638 33649 33760 33912 WOODGATE-WGF9207 WGF9213 WGFS2954

Descriptions: Primary Fuel/Water Coalescer Element with Drain

Notes: Tab/Keys are not needed for installation.

Use_With: BF7673-D, BF7674-D

Fits: Caterpillar, John Deere Equipment

UPC: 791440066403

Usually ships in 24-48 hours

Performance Data

Micron Rating:  0.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  3.27 IN   (83.06 MM)

Outer Diameter, Bottom: N/A

Inner Diameter, Top:  2.73 IN   (69.34 MM)

Inner Diameter, Bottom: N/a

Length:  6.04 IN   (153.42 MM)

Thread:  N/A

Physical Specifications
Handle:  NONE

Seal Material:

Type of Adhesive:

Type of Endcap:  PLATED STEEL

Center Tube:

Type of Media:

Filter Area:  SQ.IN.

Plating:

Outer Jacket:  YES

Configuration:  N/A FUEL/WATER SEP

Packaging Specifications
Number per Carton:  1

Carton Weight:  0.80 LB   (0.36 KG)
