MBP6180 | Interstate Filte | Sock Type Element | OFS # 97-10-0119

Performance Data
Micron Rating: 30.00 NOMINAL

Beta Rating: N/A

Collapse Pressure Rating: 75 PSID

Maximum Temperature: 250 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 25 PSID

Dimensional Specifications
Outer Diameter, Top: 6.00 IN (152.40 MM)

Outer Diameter, Bottom: 6.00 IN (152.40 MM)

Inner Diameter, Top: 2.63 IN (66.80 MM)

Inner Diameter, Bottom: 2.63 IN (66.80 MM)

Length: 18.00 IN (457.20 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material: NONE

Type of Adhesive: NONE

Type of Endcap: NONE

Center Tube: STEEL

Type of Media: COTTON

Filter Area: SQ.IN.

Plating: ELECTROTIN PLATED

Outer Jacket: YES - SOCK

Configuration: DOUBLE OPEN END

Packaging Specifications
Number per Carton: 6

Carton Weight 29.00 LB (13.15 KG) | All Online Filter Supply | replacement | parts are | equivalent | to or| interchangeable | with original manufacture parts | Names and part # used for cross reference only. |
