Performance Data
Micron Rating: 7.00
Beta Rating: N/A
Collapse Pressure Rating: 80 PSID
Maximum Temperature: 175 F
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Additional Notes: COMPRESSOR SPIN-ON, MAX. WORKING PRESSURE = 100 PSI
Dimensional Specifications
Outer Diameter, Top: 5.00 IN (127.00 MM)
Outer Diameter, Bottom: 5.00 IN (127.00 MM)
Inner Diameter, Top:
Inner Diameter, Bottom:
Length: 7.00 IN (177.80 MM)
Thread: 1.25-11BS
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive: EPOXY
Type of Endcap: N.A.
Center Tube: PLATED STEEL
Type of Media: MICROGLASS
Filter Area: 3.8 SQ.FT.
Plating: ELECTROTIN PLATED
Outer Jacket: YES
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 6
Carton Weight: 18.00 LB (8.16 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
