95674 | Big A | Spin-On Element | OFS # 97-28-8979

SPIN-ON ELEMENT Spin-On Element Usually Ships In 24-48 Hours

Performance Data
Micron Rating:  1.00 NOMINAL

Beta Rating:  B1 = 200

Collapse Pressure Rating:  100 PSID

Maximum Temperature:  225 F

Direction of Flow:  OUTSIDE->IN

Recommended Changeout Differential Pressure:  20 PSID

Dimensional Specifications
Outer Diameter, Top:  3.72 IN   (94.49 MM)

Outer Diameter, Bottom:  3.72 IN   (94.49 MM)

Inner Diameter, Top:

Inner Diameter, Bottom:

Length:  9.43 IN   (239.52 MM)

Thread:  1-14 UNS-2B

Physical Specifications
Handle:  NONE

Seal Material:  BUA-N

Type of Adhesive:  PLASTISOL

Type of Endcap:  PLATED STEEL

Center Tube:  PLATED STEEL

Type of Media:  MICROGLASS

Filter Area:  SQ.IN.

Plating:  ELECTROTIN PLATED

Outer Jacket:  YES - METAL

Configuration:  SINGLE OPEN SPIN ON

Packaging Specifications
Number per Carton:  12

Carton Weight:  24.00 LB   (10.89 KG) **All Online Filter Supply replacement parts are "equivalent" to or "interchangeable" with original manufacture parts, Names and part # used for cross reference only.**
