551578 | WIX | Pleated Paper Element | OFS # 97-28-1961
PLEATED PAPER ELEMENT
Performance Data
Micron Rating: 15.00
Beta Rating:
Collapse Pressure Rating:
Maximum Temperature:
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 6.50 IN (165.10 MM)
Outer Diameter, Bottom: 6.50 IN (165.10 MM)
Inner Diameter, Top: 5.50 IN (139.70 MM)
Inner Diameter, Bottom: 5.50 IN (139.70 MM)
Length: 15.03 IN (381.76 MM)
Thread: NONE
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive:
Type of Endcap: PLATED STEEL
Center Tube: STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating:
Outer Jacket: YES
Configuration: DOUBLE OPEN END
Packaging Specifications
Number per Carton: 1
Carton Weight: 16.40 LB (7.44 KG)
