551047 | WIX | By-Pass Lube Element | OFS # 97-28-0476

Lead Time: Usually Ships In 24-28 Hours

Performance Data
Micron Rating: 25.00

Beta Rating:

Collapse Pressure Rating:

Maximum Temperature:

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Dimensional Specifications
Outer Diameter, Top: 5.83 IN (148.08 MM)

Outer Diameter, Bottom: 5.83 IN (148.08 MM)

Inner Diameter, Top: 0.99 IN (25.15 MM)

Inner Diameter, Bottom: 0.99 IN (25.15 MM)

Length: 9.77 IN (248.16 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material:

Type of Adhesive:

Type of Endcap: PLATED STEEL

Center Tube: STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating:

Outer Jacket: YES

Configuration: DOUBLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight: 2.90 LB (1.32 KG)
