51180 | WIX | Lube Element | OFS # 97-28-0049

Lead Time: Usually Ships In 24-28 Hours

Performance Data
Micron Rating: 20.00 NOMINAL

Beta Rating: N.A.

Collapse Pressure Rating: 75 PSID

Maximum Temperature: 225 F

Direction of Flow: OUTSIDE->IN

Recommended Changeout Differential Pressure: 20 PSID

Additional Notes: COMES COMPLETE WITH COVER GASKETS.

Dimensional Specifications
Outer Diameter, Top: 3.95 IN (100.33 MM)

Outer Diameter, Bottom: 3.95 IN (100.33 MM)

Inner Diameter, Top: 1.08 IN (27.43 MM)

Inner Diameter, Bottom: 1.08 IN (27.43 MM)

Length: 5.95 IN (151.13 MM)

Thread: NONE

Physical Specifications
Handle: NONE

Seal Material: BUNA-N

Type of Adhesive: PVC

Type of Endcap: PLATED STEEL

Center Tube: PLATED STEEL

Type of Media: PAPER

Filter Area: SQ.IN.

Plating: ZINC PLATED

Outer Jacket: YES - PAPER

Configuration: DOUBLE OPEN END

Packaging Specifications
Number per Carton: 1

Carton Weight: 0.95 LB (0.43 KG)
