557024 | WIX | Pleated Paper Element | OFS # 97-28-7264
PLEATED PAPER ELEMENT
Performance Data
Micron Rating: 25.00
Beta Rating:
Collapse Pressure Rating:
Maximum Temperature:
Direction of Flow: OUTSIDE->IN
Recommended Changeout Differential Pressure: 20 PSID
Dimensional Specifications
Outer Diameter, Top: 2.06 IN (52.32 MM)
Outer Diameter, Bottom: 2.06 IN (52.32 MM)
Inner Diameter, Top: 0.83 IN (21.08 MM)
Inner Diameter, Bottom:
Length: 5.90 IN (149.86 MM)
Thread: NONE
Physical Specifications
Handle: NONE
Seal Material: BUNA-N
Type of Adhesive:
Type of Endcap: PLATED STEEL
Center Tube: STEEL
Type of Media: PAPER
Filter Area: SQ.IN.
Plating:
Outer Jacket: YES
Configuration: SINGLE OPEN END
Packaging Specifications
Number per Carton: 1
Carton Weight: 4.70 LB (2.13 KG)
